VARIOKIT tunnel formwork carriage used during the construction of the U4 subway tunnel in Hamburg

Date
09. January 2017
Technical drawing of the load-bearing system solution for the forming of single-sided walls with the help of the VARIOKIT formwork carriage construction.

Download Press Release

    Download 31.6 MB

    The images in more detail

    The following is an overview of the images contained in the press set
    1 /
    6
    VARIOKIT tunnel formwork carriage used during the construction of the U4 subway tunnel in Hamburg
    VARIOKIT tunnel formwork carriage used during the construction of the U4 subway tunnel in Hamburg
    PERI tunnel formwork system solution
    Walls and slab in one pour: A total of 71 segments are fabricated in regular weekly cycles with the VARIOKIT tunnel formwork carriage.
